Product size and weight
Lamp body size: 27.5 * 18.8 * 46cm
Outer packaging: 51 * 25 * 34cm
Gross weight: 14.5kg
Packing quantity: 1
Product parameters
Input voltage: AC100V~240V/frequency: 50~60Hz
Color temperature: 7000K
Lamp lifespan: 50000 hours
Color palette: 1 fixed color palette, 8 colors+white, rainbow effect speed adjustable, half step color effect
Pattern plate: 1 rotating pattern plate, 8 replaceable pattern plates+white light, pattern flow back and forth from slow to fast
1 fixed pattern disc, 7 cases+white light, capable of bidirectional variable speed rotation
Prism: 1 prism with adjustable rotation and speed
Beam: Multi level beam angle variation effect
Focusing: Linear focusing
Dimming: 0-100% linear adjustment
Projection range: 540 degrees in the X direction, 270 degrees in the Y direction, with automatic calibration and positioning
Scanning speed: 3.0 seconds/540 degrees in the X direction, 2.0 seconds/250 degrees in the Y direction
Beam angle: Parallel beam angle 0 ° -3 °
Magnification angle: 3 ° -30 °
Atomized light angle 8 °
Strobe: adjustable from 0.5-14 times/second
Control mode: 15 international standard DMX512 channel
Control protocol: DMX512, RDM
Appearance: High temperature resistant plastic shell, high-strength alloy cold pressed core material
Lamp body color: black
Protection level: IP20
