ELECTRICAL:
Input voltage: 100-240V, 50/60 Hz
Power：440W
LIGHT SOURCE:
Source type: RGB LED (x 400) + White LED strobe (x 200)
LED life：50.000 Hrs
* It may vary depending on various factors, such as the type of use and environment
Zoom range: RGB LED: 72° @50% / 115° @10%
Lm output: 26.526 Lm (integrating sphere)
CONTROL & CONNECTIONS:
Control channels : 5 modes with 9 / 13 / 31 / 39 / 33CH
＆#8226; Pixel engine: 75 control channels
＆#8226; Strobe engine: 25 control channels
Protocols: DMX, Art-Net, sACN, RDM
Connectors: Locking 5 pin XLR IN/OUT
Power In/Out: Power Con True1 IN/OUT
DYNAMIC EFFECTS:
Colors:
＆#8226; 400 pcs 3-in-1 RGB LEDs split into 25 areas
＆#8226; 200 pcs white LEDs split into 25 areas
＆#8226; White CT emulation 2800 – 8000 K
＆#8226; RGB and strobe shape effect
Frost:
＆#8226; Black filter (Optional)
＆#8226; White filter 20° (Optional)
＆#8226; White filter 30° (Optional)
HARDWARE & SOFTWARE:
＆#8226; Long life self-charging battery
＆#8226; Display graphic LCD backlit B/W display
＆#8226; Firmware upgrade via DMX
＆#8226; DMX monitoring
＆#8226; Remote access through RDM
Protection Rating :IP20
THERMAL SPECIFICATION:
MAX Ambient: 45°C (113°F)
Min Ambient: -20°C (-4°F)
MAX temp. of the ext. surface: 90°C (194°F)
WEIGHT & SIZES:
Weight: 5.7 Kg
Dimensions: 990 x 199 x 76 mm
